analog video cameras, they produce much less noise (even in low-light, high gain situations)
than most competing products.
Note (2): The digital gain potentiometer is factory set via a special calibration procedure to get
the maximum sensitivity without exceeding the quantization noise threshold of the A/D
converter. This potentiometer should only be adjusted in special situations by qualified operators.
5.10.4 Accesss port for digital offset control:
Access to the internal digital offset control potentiometer is provided via a 1/8” hole in the
camera cover. The range of operation is +33% and -100% (at the -100% offset point, there is no
longer any usable video signal. The Digital Offset control has a linear response.
Note (1): The digital gain potentiometer is factory set to “0” via a special calibration procedure.
This potentiometer should only be adjusted in special situations by qualified operators.
5.10.5 Access port for adjustable analog Gamma control :
An internal analog gamma control potentiometer is provided (instead of a standard 0.45 or 1.0
select switch). The range of operation is from 0.45 to 1.0 (Unity gamma). A Gamma value of
0.45 is obtained by adjusting the potentiometer to the one extreme position; unity gamma is
obtained by adjusting the potentiometer to the other extreme position. Values between 0.45 and
1.0 are obtained in between the two extreme positions.
6. DVC Camera Image Processor Compatibility
Note: The Analog Video (RS-170) Output of the DVC-0A, DVC-08 and DVC-10 will work with all
Image Processors that can accept standard RS-170 Video, including but not limited to, the
boards on the following list. (Updated March 10, 1997)
6.1 IBM (PCI)
Manufacturer Board name / no. Comments / Status
Matrox
Pulsar
Pulsar L/C (without VGA
Genesis
Available from DVC
MuTech MV-1000-10 Available from DVC
Imaging Technolgy Inc. IC-PCI/AM DIG
IM-PCI/AM DIG
Available from DVC
Dipix
XPG-1000
FPG-44
LPG-132
Available from DVC
Active Imaging Snapper BIB Available from DVC
Bitflow Data Raptor
Roadrunner (RS-422 only)
Available from DVC
Coreco
F/64
Oculus TCI-Digital
Digital-SE RS-422 only
Available from DVC
Precision Digital Imaging IMAX-PCI Available from DVC
Epix PIXCI RS-170 only (8 bits)
Imagraph Imascan precision RS-422 only (8 bits)
Univision Falcon PCI
Falcon XL
