7. Ordering Information & Model Index
7.1 DVC “DigitEyes” CAMERA MODEL INDEX
Mfr. Bits Synch.
options
Elect.
Shutter
“N”
Field
Integ.
Pulse
Driven
Integ.
Optical
Filter
Analog
Gain
Analog
Offset
Access
Ports
Analog
Gamma
Index
DVC XX S E N D I G O P Y
None None None None None Internal Internal None 0.45 0
Genlock Yes Yes Yes IR Filter External External User sp. 1.0 1
Asynch.
reset
User sp. AGC
(30dB)
0.6 2
Typical microscopy camera example: To order an analog video camera, external analog
gain/offset control (with remote control gain/offset box) and analog gamma of 1.0, order the
following:
Table 7-1: DVC-0A Ordering Example
Mfr. Bits Synch.
options
Elect.
Shutter
“N”
Field
Integ.
Pulse
Driven
Integ.
Optical
Filter
Analog
Gain
Analog
Offset
Access
Ports
Analog
Gamma
DVC XX S E N D I G O P Y
0A000001101
Example Model no: DVC-0A-0000-01101 with remote gain/offset box.
Typical digital camera example: To order a 10 Bit digital camera with asynchronous reset; pulse
driven integration; access ports for analog gain, digital gain & offset; and analog gamma = 1.0,
order the following:
Table 7-2: DVC-10 Ordering Example
Mfr. Bits Synch.
options
Elect.
Shutter
“N”
Field
Integ.
Pulse
Driven
Integ.
Optical
Filter
Analog
Gain
Analog
Offset
Access
Ports
Analog
Gamma
DVC XX S E N D I G O P Y
10200100011
Example Model no: DVC-10-2001-00011 with 3 access ports: for analog video gain, digital video
gain and offset.
