DXE-MBVE-5A Antenna Parts List
SAF-T-Tilt™ Base Assembly
(US Patent Nos. 654,064 AND 8,686,919)
Qty
Drawing Ref.
Number
Tilt Base Plate - 12” x 6” x 3/8” thick
1
1
Tilt Plate Tube - 2.5” OD x 14” x 1/4” thick, drilled
1
2
Tilt Base Insulator - 2” OD x 10”, drilled
1
3
Tilt Base Angle Bracket - laser cut and drilled
1
4
Stainless Steel Saddle for 3/8” V-Bolt
2
5
3/8” Stainless Steel V-Bolt
2
6
3/8” Stainless Steel Flat Washer
4
7
3/8” Stainless Steel Split Lock Washer
4
8
3/8”-16 Stainless Steel Hex Nut
4
9
3/8” Black Vinyl Tube Caps
5
10
1/2” Stainless Steel Hex Nut
1
11
1/2”-13 x 4-1/2” long Stainless Steel Hex Head Bolt
2
12
1/2” Stainless Steel Flat Washer, Thick
1
13
1/2” Stainless Steel External Tooth Washer
2
14
1/2” Stainless Steel Split Lock Washer
1
15
1/2”-13 Stainless Steel Flanged Nut
1
16
1/4”-20 x 3-1/4” long Stainless Steel Hex Head Cap Screw
1
17
1/4”-20 x 3/4” long Stainless Steel Hex Head Bolt
1
18
1/4” Stainless Steel Flat Washer
4
19
1/4” Stainless Steel Split Lock Washer
5
20
1/4" Stainless Steel External Tooth Washer
5
21
1/4”-20 Stainless Steel Hex Nut
5
22
1/4”-20 x 2-3/4” long Stainless Steel Hex Head Cap Screw
2
23
7” 14 ga PVC insulated wire with two 1/4 Round Terminals
1
24
24-1/2” 14 ga PVC insulated wire with one 1/4 Round Terminals
1
For Auto Tuner option
Vertical Antenna Elements and Band Clamps
Qty
2.125" (2-1/8”) x 0.058" x 36" Tube (Slit one end, drilled)
1
2.000" (2”) x 0.058" x 36" Tube (Slit one end)
1
1.875" (1-7/8”) x 0.058" x 36" Tube (Slit one end)
1
1.750" (1-3/4”) x 0.058" x 36" Tube (Slit one end)
1
1.625" (1-5/8”) x 0.058" x 36" Tube (Slit one end)
1
1.500" (1-1/2”) x 0.058" x 36" Tube (Slit one end)
1
1.375" (1-3/8”) x 0.058" x 36" Tube (Slit one end)
1
1.250" (1-1/4”) x 0.058" x 36" Tube (Slit one end)
1
1.125" (1-1/8”) x 0.058" x 36" Tube (Slit one end)
1
1.000" (1”) x 0.058" x 36" Tube (Slit one end)
1
0.875" (7/8”) x 0.058" x 36" Tube (Slit one end)
1
0.750" (3/4”) x 0.058" x 36" Tube (Slit one end)
1
0.625" (5/8”) x 0.058" x 36" Tube (Slit one end)
1
0.500" (1/2”) x 0.058" x 36" Tube (Slit one end)
1
0.375" (3/8”) x 0.058" x 36" Tube (no slits)
1
DXE-ECL-0500 - Element Clamp
1
DXE-ECL-0625 - Element Clamp
1
DXE-ECL-0875 - Element Clamp
2
DXE-ECL-1000 - Element Clamp
2
DXE-ECL-1250 - Element Clamp
1
DXE-ECL-1500 - Element Clamp
2
DXE-ECL-1750 - Element Clamp
2
DXE-ECL-2000 - Element Clamp
2
DXE-ECL-2250 - Element Clamp
1
