Appendix D - MFJ-998RT Remote Tuner Installation
There are two complete DXE-MBVE-5A systems for use with the MFJ-998RT Remote Tuner
DX Engineering
MBVE-5A
Model Numbers
MFJ-998RT
Tuner
1500 Watt
There are two upgrade retrofit kits for existing DXE-MBVE-5/5A systems for use with the MFJ-
998RT remote tuner. One with the tuner, one for use if the customer already has the tuner.
Upgrade kits include new longer base tube, brackets, remote tuner as selected below.
DX Engineering
Upgrade Model
Numbers
DXE-MBVE-
TBHW
Hardware Kit
DXE-MBVE-5A-
UGHW
Hardware Kit
MFJ-998RT -
Tuner
1500 Watt
General Information
For new antenna installations (DXE-MBVE-5AE-RT or 5AERT8), the antenna is installed as
previously out lined in this manual. Additional clamps and hardware are included for mounting the
MFJ-998RT Remote Tuner. The mounting method for this remote tuner is outlined in this section
of the manual.
For an upgrade to an existing DXE-MBVA-5/5A (as shown in the chart above), the parts in the
upgrade kits are installed as outlined in this section of the manual. These MFJ Remote Antenna
Tuner Add-on Kits for the DXE-MBVA-5/5A 43 Foot Multi-band Vertical Antenna are made for
using the MFJ-998RT 1500 Watt remotely mounted automatic tuner which will greatly enhance the
operating capabilities of the 43 foot antenna system.
Now you can have full performance 160-10 meters with no mismatch coaxial cable loss. A Bias-
Tee from MFJ is included with the MFJ-998RT remote tuner for supplying the +12 Vdc power
through the coaxial cable from your radio shack to the remote tuner.
