7
Names of Parts
1. Speaker 2. Lens Cover/Power Switch 3. Shutter Button
4. Flash 5. Red-eye Reduction Device 6. Microphone
7. Self-timer LED 8. Macro Switch Button 9. Lens
10. Connector Cover 11. TV-Out Port 12. USB Port
Shutter Button
The Shutter button is used to take pictures in the Picture Mode or start
recording video or Movie/Video Mode.
Lens Cover
The lens cover when slid open will turn the camera’s power on automatically. To
turn the power off, slide the lens cover back.
USB Cover
Open the USB cover to find the USB and TV-Out ports.
Getting to Know Your Camera
Front View
