Dyna-Glo DGP321SNP - Page 13

13
GG
F
D
F
D
Hardware Used
GG
M6x10
Flat Bolt
x8
13
ASSEMBLY INSTRUCTIONS
13. Attach the side shelf bracket A (D) and side
shelf bracket B (F) to the grill body assembly
(C) with eight M6x12 at bolts (GG).
D
F
F
GG
Hardware Used
GG
M6x12 Flat Bolt
x 8
AA
BB
DD
CC
M6
Plain
Qty. 2
M6
Qty. 2
M6x16
Bolt
Qty. 18
Washer
EE
M6x35
Bolt
Qty. 4
Washer
FF
M6
Wing Nut
Qty. 2
GG
M3x10
Bolt
Qty. 4
HH
M6x12
Flat Bolt
Qty. 8
Shoulder
Bolt
Qty.4
II
Qty. 1
Wrench
Spring
D
C
C
