24
Heat Tents
Cooking Grates
Warming Rack
Figure 1 Figure 2
Figure 2
CARE AND MAINTENANCE
Burner Assembly
Removing The Burner Assembly
1. Make sure all control knobs are in the OFF
position, gas supply valve is closed, and the
gas hose is disconnected from the gas supply.
2. Open lid and remove warming rack, cooking
grates, and heat tents.
3. Remove hinge pin as illustrated in Figure 1.
4. Slide main burners out of rebox.
5. Detach ignition wire from electrode in Figure 2.
Figure 1
Heat Tents
Cooking Grates
Warming Rack
