ASSEMBLY INSTRUCTIONS
12. Attach the door handle assembly (D) to the door
assembly (C) using 1 #10-24 x ½” screw (DD).
13. Attach the door latch bracket (P) to the door
assembly (C) using 2 #10-24 x ½” screws (DD).
C
P
DD
C
12
13
D
Hardware Used
DD
#10-24 x ½”
Screw
x 2
DD
Hardware Used
DD
#10-24 x ½”
Screw
x 1
