16
ASSEMBLY INSTRUCTIONS
14. Remove the pre-installed washer and nut from the
temperature gauge (M) and insert the probe
through the middle hole of the door assembly (C).
Secure with pre-assembled washer and nut.
15. Attach the door assembly (C) to the smoker
cabinet assembly (A).
15
C
M
14
A
C
