Dyna-Glo DGX780BDC-D - Assembly Instructions; Initial Assembly Steps (1-4)

6
ASSEMBLY INSTRUCTIONS
CAUTION: Remove the upper (P) and lower (Q)
doors before beginning assembly.
1. Remove the upper (P) and lower (Q) doors by
opening and sliding the doors up and off
the hinges.
2. With smoker body (G) turned upside down,
attach legs (H) to smoker box (G) using
twelve M6x12 screws (AA)
Hardware Used
AA
M6 x 12mm
Screw
x 12
1
Q
P
2
H
G
AA
