40SERIES 50SERIES 60SERIES
1 INNERSHELLASSEMBLY 1 2304818 2304818 2304818
2 NOZZLE 1 *2304829 *2304942 *2325121
3 FLAMECAP 1 2304819 2304819 2325120
4 THERMALSWITCHBRACKET 1 2304826 2304826 2304826
5 THERMALSWITCH 1 2201373 2201563 2201599
6 NOZZLENUT 1 2304578 2304578 2304578
7 SPARKPLUGASSEMBLY 1 2201375 2201375 2206033
8 THERMOCOUPLEASSEMBLY(1130/1474‐425L) 1 2304885 2304885 2304885
9 GASTUBINGASSEMBLY 1 2304830 2304830 2304830
OUTERSHELL‐ORANGE 1 2305403 2305403 2305403
OUTERSHELL‐BLACK
1 2315915 2315915 2315915
OUTERSHELL‐GRAY 1 2315956 2315956 2315956
OUTERSHELL‐BLUE 1 2315312 2315312 2315312
11 CORDWRAP(selectmodelsonly) 2 N/A N/A N/A
HANDLEASSEMBLY‐BLACK 1 2101447 2101447 2101447
HANDLEASSEMBLY‐GRAY 1 2305426 2305426 2305426
12.1 SCREW‐HANDLEFRONT 1 2001355 2001355 2001355
12.2 SCREW‐HANDLEFRONT 1 2001077 2001077 2001077
12.3 NUT‐HANDLEREAR 1 2000384 2000384 2000384
13 MOTORSUPPORT 1 2304823 2304823 2304823
13.1 MOTOR‐MOUNTINGBOLT 2 2001332 2001332 2001332
13.2 SLEEVE 1 2304949 2304949 2304949
14 MOTORASSEMBLY 1 2305909 2305447 2304547
14.1 MOTOR‐FAN 1 2304821 2304821 2304821
FANGUARD‐BLACK 1 2304828 2304828 2304828
FANGUARD‐GRAY 1 2305411 2305411 2305411
16 MOTORBRACKET 1 2304937 2304937 2304937
17 VALVE‐GAS 1
5050200 5050510 5051033
18 PRESSURESWITCH 1
N/A N/A N/A
19 VALVEBRACKET 1 2304624 2304624 2304624
BASEASSEMBLY‐BLACK 1 2304923 2304923 2304923
BASEASSEMBLY‐GREY 1 2305405 2305405 2305405
21 POWERCORDASSEMBLY 1 2201368 2101670 2101670
22 GASCONNECTORINLET 1 2304831 2304831 2304831
23 CAPACITOR 1 2201372 2201372 2201372
BASELOWER‐BLACK 1 2304925 2304925 2304925
BASELOWER‐GREY 1 2305407 2305407 2305407
KNOBGASVALVE‐BLACK 1 2101451 2101451 2101451
KNOBGASVALVE‐ORANGE 1 2305466 2305466 2305466
HEIGHTCONTROLLER‐BLACK 1 2304927 2304927 2304927
HEIGHTCONTROLLER‐GREY 1 2305409 2305409 2305409
HEIGHTCONTROLSCREW‐BLACK 1 2304510 2304510 2304510
HEIGHTCONTROLSCREW‐ORANGE 1 2305467 2305467 2305467
28 LEADWIREASSEMBLY 1 2201371 2201371 2201371
29 SPARKMODULE 1 N/A 2201391 2201391
30 PCBASSEMBLY 1 2201369 2201369 2201369
REG&HOSEASSEMBLY‐10FT(3M) 1 *5002199 *5002614 *5002614
REG&HOSEASSEMBLY‐10FT(3M)w/HANDWHEEL 1 *5002540 *5055533 *5055533
REG&HOSEASSEMBLY(QCC)‐10FT(3M) 1 TYQ‐9C‐3000 TYQ‐10C‐3000 TYQ‐10C‐3000
REG&HOSEASSEMBLY‐15FT(4.6M) 1 *5055297 *5055298 *5055298
REG&HOSEASSEMBLY‐15FT(4.6M)w/HANDWHEEL
1 *5055414 *5055415 *5055415
REG&HOSEASSEMBLY(QCC)‐15FT(4.6M)
1 TYQ‐9C‐4572 TYQ‐10C‐4572 TYQ‐10C‐4572
DESCRIPTION
PARTNUMBER
10
12
15
QTY
25
26
27
31
ITEMNo.
20
24
* VERSION NOT SHOWN IN EXPLODED VIEW
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
 16
