NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS LIST
FA100DGP FA125DGP LPFA125DGD
1 INNERSHELLASSEMBLY 1 2304929 2304929 2304929
2 NOZZLE 1 *2304943 5030077 5030077
3 FLAMECAP 1 2304930 2325122 2325122
4 THERMALSWITCHBRACKET 1 2304826 2315515 2315515
5 THERMALSWITCH 1 2201373 2201373 2201373
6 NOZZLENUT 1 2304578 2304945 2304945
7 SPARKPLUGASSEMBLY 1 2201392 2206034 2206034
8 THERMOCOUPLEASSEMBLY(1130/1474425L) 1 2304885 2304885 2304885
9 GASTUBINGASSEMBLY 1 2305975 2325137 2325137
OUTERSHELLORANGE 1 2305971 2305971 N/A
OUTERSHELLBLACK 1 N/A N/A 2403443
11 CORDWRAP 2 2101423 2101423 2101423
12 MOTORSUPPORT 1 2304823 2304823 2304823
12.1 MOTORMOUNTINGBOLT 2 2001332 2001332 2001332
12.2 SLEEVE 1 2304949 2304949 2304949
13 MOTORASSEMBLY 1 2304548 2304548 2304548
13.1 MOTORFAN 1 2304936 2304936 2304936
FANGUARDGRAY 1 2305412 2305412 N/A
FANGUARDBLACK 1 N/A N/A 2304939
15 MOTORBRACKET 1 2304938 2304938 2304938
16 BASERIGHTSIDE 1 2306000 2306000 2306000
17 LEGHOLDER 2 2315002 2315002 2315002
18 CAPACITOR 1 2301390 2301390 2301390
19 PRESSURESWITCH 1
2305976 2305976 2305976
20 POWERCORDASSEMBLY 1 2101673 2101673 2101673
21 GASCONNECTORINLET 1 2304831 2304831 2304831
22 BASEBOTTOM 1
2315001 2315001 2315001
23 VALVEBRACKET 1
2305973 2305973 2305973
24 VALVEGAS 1
5051234 5051235 5051235
25 BASELEFTSIDE 1
2305999 2305999 2305999
KNOBGASVALVEORANGE 1 2101588 2101588 N/A
KNOBGASVALVEBLACK 1 N/A N/A 2101451
HEIGHTCONTROLSCREWORANGE 2 2315003 2315003 N/A
HEIGHTCONTROLSCREWBLACK 2 NA NA 2403444
REGULATOR&HOSEASSEMBLY10FT(3M) 1 *TYQ6D1LL3800 *TYQ6D1LL3800 N/A
REGULATOR&HOSEASSEMBLY(QCC)10FT(3M) 1 N/A N/A TYQ6D13000
REGULATOR&HOSEASSEMBLY15FT(4.6M) 1 *5055548 *5055548 N/A
REGULATOR&HOSEASSEMBLY(QCC)15FT(4.6M) 1 N/A N/A TYQ6D14572
29 LEG 1 2305972 2305972 2305972
30 LEADWIREASSEMBLY 1 2201371 2201371 2201371
31 SPARKMODULE 1 2201391 2201391 2201391
32 PCBASSEMBLY 1
2201369 2201369 2201369
*VERSIONNOTSHOWNINEXPLODEDVIEW
