dynabook Portege X40L-K Series User Manual

4.11.1 Removing the Battery pack
To remove the battery pack, follow the steps below.
1. Disconnect the BATTERY HARNESS from the connector CN8021 on
the System board.
2. Remove the following screws and the battery pack.
Figure 4-6 Releasing the battery pack
Take care not to short circuit the terminals when removing the battery
pack. Similarly, do not drop, knock, scratch, disassemble, twist, or bend
the battery pack.
CN8021 IN
C
SU
1
2
Battery Harness
Dispose of the used/removed battery pack in accordance with the laws and
ordinances of your local authority.
