4.5 SODIMM 4 Replacement Procedures
Satellite C40-G/Pro-C40-G Maintenance Manual 4-13
4.5 SODIMM
Removing SODIMM
Remove SODIMM according to the following procedures and Figures 4-14.
CAUTION: Do not touch the connectors on SODIMM and in the computer with your bare
hands. SODIMM can fail if they are contaminated with sweat, natural oils, etc. from your
hands.
1.Press both sides of the J1 connector shrapnel 15° with both index fingers
2.Take out the SODIMM at 45° horizontal
Figure 4-14 Removing SODIMM
