dynabook Satellite C40-G User Manual

错误 ! 未找到引用源。 13 CCD Module 4
Replacement Procedures
Satellite C40-G/Pro-C40-G Maintenance Manual 4-32
42
4.13 CCD Module
NOTE: Touch SKU will provide the FRU parts as LCD Module Assembly. This chapter
only for Non-Touch SKU.
Removing the CCD Module
Remove the CCD Module according to the following procedures and Figure 4-33
1. Lift the CCD Module from the LCD module cover.
2. Disconnect LCD cable from CCD Module connector.
Figure 4-33Removing the CCD Module

dynabook Satellite C40-G Specifications

General

Display	14.0-inch
Display Resolution	1920 x 1080
Graphics	Intel UHD Graphics
Operating System	Windows 10
Weight	1.55 kg
Wireless	Bluetooth 5.0
Ports	HDMI, RJ-45, Headphone/Microphone combo jack
Dimensions	328 x 224 x 18.9 mm
