5 Specification
DPC 8015
Supply Voltage 15...58 V DC
Maximum Supply Current
(without extensions)
< 80 mA / 24 V
< 110 mA / 18 V
Maximum Supply Current
(with 5 extensions DPC 8120)
< 180 mA / 24 V
< 250 mA / 18 V
CAN Interface 10...500 kbit/s, 1 x RJ-45, max. length 1000 m
Maximum Mic Input Level -21 dBu
Maximum Line Input Level +4 dBu
Maximum NF Output Level +12 dBu
Buttons 5 pre-programmed, 15 programmable zone/function keys
LEDs Power (green), Fault (yellow), Alarm (red)
Green LED per pre-programmed menu button
Green and yellow LED per programmable zone/function key
LC-Display Lighted LC display (122 x 32 pixel)
External Connectors 1 PCA BUS connector (Control data + Audio + Power supply, RJ-45)
1 Audio Source (Line level, phone jack)
1 Microphone input (phone jack)
1 EXT connector (Console Extension, RJ-12)
Operating Temperature Range -5 °C ... +45 °C
Dimensions (W x H x D) 200 x 167 x 65 mm (without microphone)
Weight 0,6 kg
Options
Emergency Button EB DPC (Part No.: D 121 963)
Key Switch NRS 90231 (Part No.: D 121 721)
DPC 8120
Buttons 20 programmable zone/function keys
LEDs Green and yellow LED per programmable zone/function key
External Connectors 2 EXT connectors
Operations Temperature Range -5 °C...+45 °C
Dimensions (W x H x D) 140 x 167 x 65 mm
Weight 0,35 kg
