Dynamic Rhino User Manual

Rhino to RHINO2 Conversion Guide Page 12
Adapting DS162K to DS160
To adapt a DS162K loom to a DS160
loom, use the RHINO2 MTR-4/RING
ADAPT LOOM (part no., GLM51985),
and the RHINO2 BATT-6/RING ADAPT
LOOM (part no., GLM51986).
GLM51985: Fit connector to existing motor loom
connector, and the ring terminals to RHINO2’s motor
connectors.
GLM51985: Fit connector to existing
battery loom connector, and the ring
terminals to RHINO2’s battery
connectors.
Note:
The torque settings for the DS160 and DS160-ACT motor and battery terminals should be
between 4.5Nm and 5.5Nm
