Rhino to RHINO2 Conversion Guide Page 11
Adapting DS112K to DS120
To adapt a DS112K loom to a DS120 loom,
use the DS120 MTR/PB ADAPT LOOM (part
no., GLM51983). This is suitable for motor
looms using Dynamic Controls GCN51315
housing.
GLM51983: Fit to RHINO2 motor connector socket
GLM51983: Fit to existing motor loom
connector
GLM51983: Fit to RHINO2 park brake connector socket
For more information, see the
RHINO2 Installation Manual,
The DS52K, DS72K and DS112K do not require a battery adaptor loom. Simply connect the
existing scooter battery connector directly into the RHINO2 controller’s battery connector.
