Operation
2018-02-19 4812325557EN 49
Low tire pressure – 240 kPa (34,8 PSI)
The lower the tires pressure, the lower the pressure on the
contact surface, due to the larger surface area.
Normal tire pressure – 480 kPa (69,6 PSI)
Used for degradation session.
High tire pressure – 830 kPa (120,4 PSI)
The higher the tires pressure, the higher the pressure on the
contact surface, due to the smaller surface area.
Fig. - Low ground pressure, larger contact
area
Fig. - Normal ground pressure
Fig. - High ground pressure, smaller contact
area
