Specifications
2018-02-19 4812325557EN 67
Torque (cont.)
METRIC COARSE
THREAD, ZINC-
TREATED
(Dacromet/GEOMET)
STRENGTH CLASS
10.9
oiled
10.9
dry
12.9
oiled
12.9
dry
M6
12 N.m
(8.8 lb.ft)
15 N.m
(11.06 lb.ft)
14.6 N.m
(10.7 lb.ft)
18.3 N.m
(13.4 lb.ft)
M8
28 N.m
(20.6 lb.ft)
36 N.m
(26.5 lb.ft)
34 N.m
(25.07 lb.ft)
43 N.m
(31.7 lb.ft)
M10
56 N.m
(41.3 lb.ft)
70 N.m
(51.6 lb.ft)
68 N.m
(50.1 lb.ft)
86 N.m
(63.4 lb.ft)
M12
98 N.m
(72.2 lb.ft)
124 N.m
(91.4 lb.ft)
117 N.m
(86.3 lb.ft)
147 N.m
(108.4 lb.ft)
M14
156 N.m
(115 lb.ft)
196 N.m
(144.5 lb.ft)
187 N.m
(138 lb.ft)
234 N.m
(172.5 lb.ft)
M16
240 N.m
(177 lb.ft)
304 N.m
(224.2 lb.ft)
290 N.m
(213.9 lb.ft)
360 N.m
(265.5 lb.ft)
M20
470 N.m
(346.6 lb.ft)
585 N.m
(431.4 lb.ft)
560 N.m
(413.03 lb.ft)
698 N.m
(514.8 lb.ft)
M22
626 N.m
(461.7 lb.ft)
786 N.m
(579.7 lb.ft)
752 N.m
(554.6 lb.ft)
944 N.m
(696.2 lb.ft)
M24
800 N.m
(590 lb.ft)
1,010 N.m
(744.9 lb.ft)
960 N.m
(708.05 lb.ft)
1,215 N.m
(896.1 lb.ft)
M30
1,580 N.m
(1,165.3 lb.ft)
1,990 N.m
(1,467, 7 lb.ft)
1,900 N.m
(1,401.3 lb.ft)
2,360 N.m
(1,740.6 lb.ft)
Wheel bolts
Bolt dimensions
M20 (PN 4700792683)
Strength class
10.9
Torque
Oiled: 494 N.m (364.5 lb.ft)
Dry: 620 N.m (457.2 lb.ft)
Hydraulic system
OPENING PRESSURE
Steering system
160 BAR
2,320 PSI
Transmission system
330 BAR
4,786 PSI
Supply system
2 BAR
29 PSI
Brake release
19 BAR
275 PSI
