Maintenance - Every 50 hours
82 4812325557EN 2018-02-19
Check and replace the secondary air filter
Replace the backup filter when the main air filter is
replaced for the third time.
To replace the backup filter for a new one, follow the instructions
below:
1. Remove the old backup filter (1) from the holder, install a
new on and fit the components back in the reverse order.
2. Clean the main filter, if necessary.
Replace the engine fuel filter
The fuel filter is located in front of the accumulators, on the left
side of the engine compartment.
1. Unscrew the bottom of the filter and drain the water. Next,
screw the unit back in its place.
2. Fit the fuel filter in the correct place, turn on the engine and
check if the filter is well sealed.
Fig. – Air filter
1. Backup filter
Fig. – Engine compartment
1. Filter
1
