Connection and Control Elements
CONNECTIONS AND CONTROL ELEMENTS
Digital audio
Digital connection. IN = input, OUT = output
Analog audio
Analog connection. IN = input, Input sensitivity = manual correction of the input sensitivity (+6/0/–6 dB)
Service
USB port for rmware update
Speaker position
Sound adjustment (depending on the position of the loudspeakers). Sound adjustment is performed with
a rotary knob with 7 positions. With the 3 main positions, the rotary knob clicks into place:
Neutral = with free-standing placement. Wall = if placed near a wall. Corner = if placed in a corner
Treble
Treble adjustment (+1/0/–1 dB)
Zone
Selecting the audio zone (Xeo hub operation)
Loudspeakers assigned to different zones can be controlled separately via the remote control.
The zones are identied as Red, Green, and Blue.
Channel mode
Master = loudspeaker operated as master. Slave = loudspeaker operated as slave.
External = loudspeaker congured as active loudspeaker (at full performance)
Power
Power switch. I = The loudspeaker is on. The loudspeaker can be activated and deactivated via the remote
control. If the loudspeaker is activated and there is no signal, it will switch to standby mode.
O = The loudspeaker is completely off.
Treble
Mains socket. To connect the loudspeaker to the mains voltage.
