Barrel Diameter
Support Vendors
The support vendor list shows the address for a bore gage manufacturer. Once
the barrel is extremely clean, all dimensional measurements are to be made at
room temperature it can be checked using a bore gage. Be sure to get or make a
long enough extension so the entire barrel can be checked. The barrels measure
0.3760 +/- .0002 leaving the factory.
Reference the section “Series 4000: A Guided Tour"; Selecting TEST in the
SYS Mode” to perform any hardware tests.
1. Pin Gages
Calibration or Certification of Cylindrical Pins
Zero Check
P.O. Box 903
Thomaston, Connecticut 06787
Tel: 203-283-5629
FAX: 203-283-4113
Meyer Gage Company
230 Burnham St.
South Windsor, CT 06074
(203) 528-6526
Ask for Class X pins (ISO specs are 0.0002 of nominal, ASTM specs
(D3835) are 0.0003 of nominal)
2. Cleaning Patches
Skyline Center Inc.
P.O. BOX 3064
Clinton, IA 52732
(319) 243-4065
(800) 747-4065 Extension-4065
FAX (319) 243-9901
3. Bore Gages
Inspex Corp.
664 Bussee Hwy.
Park Ridge, IL 60068
(708) 825-2200, Fax 825-0825
Order Diameter Probe #029 Probe, N-6 Needle, 0.0001 dial indicator,
8 mm holder, #029 ring (0.375"), 0.315" x 10" Depth Extension
4. NIST Standard Reference Materials (SRM)
For example: Standard Material 1476 is a branched polyethylene with
(a MFR of 1.19 0.01) as of 1992 cost about $255 for 50 grams.
SRM Catalog number is NIST Special Publication 260
To order: (301) 975-6776 Fax (301) 948-3730
5. Hg spill kits
Mercury Clean Up Spill Kits
Series 4000 Melt Indexer Operation Manual Instrument Maintenance and Troubleshooting
64
