Installation Instructions for
2002 GSX1300R Hayabusa
These instructions cover the installation for the PCIII and the
PCIIIr with ignition.
The ignition MUST be turned off before installation!!
1 Remove the main seat and the passenger seat.
2 Hold the front of the fuel tank up using the prop rod located
in the trunk area.
3 Locate the connector from the main wiring harness to the
injector rail and uplug this connector (Fig. A).
NOTE: This connector is white in color.
Fig.A
PLEASE READ ALL THE DIRECTIONS BEFORE
STARTING INSTALLATION
Unplug this connector
