Dynojet Power Commander 3r - Connect PCIII to Wiring Harness; Route PCIII Wiring; Connect Ground Wire to Battery

10 3
Fig.B
4 Plug the connectors from the PCIII in-line of the stock
wiring harness (Fig. B).
Fig.C
5 Route the PCIII wiring along the inside of the frame
towards the battery.
6 Attach the ground wire from the PCIII to the negative side
of the battery (Fig. C).
Stock connectors
PCIII connectors
Ground wire
from the PCIII.
View from L.H side
