Fitting notes
Service manual
15
Switch - removal
29 Remove the cyclone and bin
assembly from the product.
Remove the T-15 screw in the
stow bracket.
30 Carefully release one side of the
stow bracket away from the
chassis to release it.
Repeat on the other side.
31 Carefully slide a thin flat bladed
screwdriver between the switch
actuator and switch housing
where shown. Carefully prise the
actuator out of the housing.
Remove the spring.
