Dyson DC26 Service Manual

Technical info.
Service manual
Resistance values
03
Wiring schematic
Cable rewind/
cable wiring assembly
Motor bucket
On/Off
switch
Cyclone
inlet
Contacts
1
2
3
5
7
9 10
8
4
6
COMPONENT
POWERCORD ASSY
1
2
5
POWERCORD ASSY
POWERCORD TO MAIN ON/OFF SWITCH
MAIN CHASSIS AND MOTOR ASSY
(WITH CABLE REWIND ATTACHED)
(WITH CABLE REWIND REMOVED)
MAIN ON/OFF SWITCH
TEST BETWEEN POINTS
OHMS
3
4
7
TO
1 Ω MAX
1 Ω MAX
1 Ω MAX
6 Ω APPROX
1 Ω MAX
1
2
TO
7
8
TO
9
10
TO
TO
TO

Dyson DC26 Specifications

General

Suction power	160 AW
Maximum input power	- W
Annual energy consumption	- kWh
Proper use	Home
Noise level	- dB
Removable filter	Yes
Cleaning surfaces	Carpet, Hard floor
Vacuum air filtering	HEPA
Dirt separating method	Filtering
Type	Cylinder vacuum
Cordless	No
Cleaning type	Dry
Dust capacity	- L
Product color	Blue, Transparent
Tube material	The material the tube is made of.
Dust container type	Bagless
Cord length	5 m
Dust capacity dry	0.68 L
Vacuum brushes included	Hard floor brush

Weight and Dimensions

Weight	5200 g
