43 Carefully remove the cable rewind
actuator and spring, as previously
shown (page 16, step 32).
44 Peel the end of the inlet seal from
the chassis.
Note: the inlet seal is spot glued
in several places.
Undo the Torx T-8 screw.
45 Prise the brake wheel stopper out
of the chassis.
Brake wheel assy - removal
