Fitting notes
Service manual
25
55 Carefully prise the cyclone inlet
out of the catch detail on the side
of the chassis .
56 Carefully release the ESD wire
and tab from the cyclone inlet.
57 If replacing any of the parts
attached to the cyclone inlet,
remove the screw in the underside
of the inlet.
