13.2 FLUE GAS ANALYSIS - PRELIMINARY OPERATIONS
Insert the gas sample probe in
the chimney:
Models (with automatic
autozero solenoid) E4500
Do not insert the gas sample
probe in the chimney:
Models (without solenoid)
1500
07/08/14
10:00
Analysis
Operator
Information
Language
Instrument
Alarms
Diagnostic
Configuration
Restore
07/08/14
10:00
Save
Select
Delete
Average
Data logger
Usage %
Memory
PARAMETERS TO SET BEFORE
PROCEEDING (SEE SECTION 10.0):
Select
Data logger
PARAMETERS TO SET BEFORE
PROCEEDING (SEE SECTION 9.0):
Analysis
Operator
Hold down
for a
few
seconds
07/08/14
10:00
Eff. tot
%
91.4
Loss tot
%
8.6
∆T
°C
74.7
T air
°C
15.4
T flue
°C
190.1
Ex. Air
1.25
CO
2
%
9.3
O
2
%
4.2
Combustion analysis
07/08/14
10:00
Eff. tot
%
91.4
Loss tot
%
8.6
∆T
°C
74.7
T air
°C
15.4
T flue
°C
190.1
Ex. Air
1.25
CO
2
%
9.3
O
2
%
4.2
Combustion analysis
Serial number: 1000
Firmware version: 1.00
E4500-N
