ANNEX A
Example of Total analysis report.
Analysis: 1
04/04/14 10.00
O 2 4.2 ٪
CO 2 9.3 ٪
Ex. Air 1.25
T flue 190.2 °C
T air 15.4 °C
∆T 174.8 °C
Loss tot 8.6 ٪
Eff. tot 91.4 ٪
ηc
4.9 ٪
ηt 91.4 ٪
CO 148 ppm
NO 40 ppm
NO X /NO: 1.03
NO X 41 ppm
Analysis: 2
04/04/14 10.15
O 2 4.4 ٪
CO 2 9.2 ٪
Ex. Air 1.26
T flue 190.2 °C
T air 15.4 °C
∆T 174.6 °C
Loss tot 8.7 ٪
Eff. tot 91.4 ٪
ηc 4.9 ٪
ηt 91.4 ٪
CO 145 ppm
NO 40 ppm
NO X /NO: 1.03
NO
X 41 ppm
Analysis: 3
04/04/14 10.20
O 2 4.2 ٪
CO 2 9.3 ٪
Ex. Air 1.25
T flue 190.1 °C
T air 15.4 °C
∆T 174.7 °C
Loss tot 8.7 ٪
Eff. tot 91.4 ٪
ηc 4.9 ٪
ηt 91.4 ٪
CO 146 ppm
NO 40 ppm
NO X /NO: 1.03
NO X 41 ppm
COMPANY Ltd.
Park Road, 9
Tel.800-555-1234
Oper.: John Smith
Sign.: ______________
Test according to
UNI 10389-1
E4500-3
Serial: 999989
Memory: 01
Analysis: Average
Date: 04/04/14
Time: 10.30
Fuel: Natural gas
Altitude: 0 m
R.H. air: 50 %
MEASURED VALUES
T flue 191.1 °C
T air 15.4 °C
O2 4.2 ٪
CO 146 ppm
NO 40 ppm
CO amb 0 ppm
Draft: 0.05 hPa
CALCULATED VALUES
Ex. Air 1.25
CO2 9.3 ٪
Loss tot 8.6 ٪
Eff. tot 98.5 ٪
ηc
4.9 ٪
ηt 103.4 ٪
∆T 174.7 ٪
NO X /NO: 1.03
NO X 41 ppm
Ref. O 2 : 0.0 ٪
CO 182 ppm
Ref. O 2 : 0.0 ٪
NO 50 ppm
Ref. O 2 : 0.0 ٪
NO X 51 ppm
Note: ------------------
------------------------
------------------------
------------------------
------------------------
------------------------
