9.3.4 Configuration→Instrument→Pump
CONTEXT KEY FUNCTION
Enters edit mode: it is possible to turn the gas suction pump on or off.
Confirms the modification.
OK
→
KEY FUNCTION
Activate the context keys shown on the display.
When in modify mode, sets the desired value.
When pressed in modify mode cancels the selection made, otherwise
returns to the previous screen.
Enters edit mode of the selected element and then confirms the change.
Configuration
Pump
07/08/14
10:00
Flow
l/min
1.2
Pump on
Displays the flow of the pump, expressed in litres per minute.
