H695 Series Router User Manual
E‐LinsTechnologyCo.,Limited
Add:Bld22.,LongxiGarden,NonglinRD.,FutianDistrict,Shenzhen,518000,China
Tel:+86‐0755‐81220758Fax:+86‐755‐83700465E‐mail:sales@e‐lins.comwww.e‐lins.com
3.2 The LED State
In order to know state of module there are four LED lamps, Online, Run, LAN and Cell altogether, and among
them, the concrete explanation is as follows to the different states of pilot lamp representative:
Online Blink Winked
Online
Connected data transmission
after got the IP when it light on
Failed to connect or
data transmit when light
off.
Run
show the state of initialization
system with others when the
equipment is started
Run normally and Data
transmitting when it’s lighting...
LAN
Ethernet links normal when it
light on
Data transmitting by Ethernet
interface when lighting
None Ethernet connects
Cell
Module wok normally
The system work LED state explanation
Online Run LAN Cell
Power supply Online1~2s Online1~2s
System checking First blink 2 times And then blink 2 times
System checking again First blink 2 times And then blink 2 times
Checking cellular module The lights winked. The lights winked.
Start program blink 8s Off
Work normally online Blink blink
3.3 Connect to products
1. Please connect antenna and RJ45 cable with our products,
