E-T-A PowerPlex CM500 - Technical Data; Table 4: Selection of Technical Data

14
4.1. Technical data
The technical information of the PowerPlex
®
Compact Module are summarised in Table 4.
Technical Data
Rated voltage
DC 12 V/24 V
Operating voltage
9 ... 32 V DC
Current consumption
typically 63 mA at 12 V
typically 44 mA at 24 V
Max. total current
60 A per module
Degree of protection
IP22 when mounted vertically with terminals pointing downwards
Operating temperature range
-30 … +70°C (-22 … 158 °F)
with derating above +50 °C (+122 °F)
Storage temperature range
-30 … +85°C (-22 … 185 °F)
mass
approx. 410 g
Interfaces:
CAN I*
PowerPlex® CAN, 250 kbit/s, galvanically isolated
CAN II*
CAN II galvanically isolated, protocol upon request
*) The CAN-terminals at each end of a CAN bus require a termination by a 120 Ω resistor.
LIN
LIN bus interface (CI-BUS) upon request
Inputs:
8 multifunctional inputs, configurable as
I1
I2
I3
I4
I5
I6
I7
I8
digital input:
0 … 8 kΩ: ON; > 10 kΩ OFF;
plus or minus switching
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
analog inputs:
a)
voltage monitoring:
0 … 32 V, R
in
: 60 kΩ;
resolution: 10 Bit
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
b)
battery monitoring:
± 60 mV; battery current
measurement with external shunt
(I3 & I4)
+
-
c)
resistance measurement:
0 ... 750 Ω; for tank levels and
temperature
⚫
⚫
⚫
⚫
⚫
⚫
⚫
⚫
d)
frequency measurement:
0 … 10 kHz (I1 & I2)
⚫
⚫
Outputs
10 outputs with 10 A max. continuous current
load output
Power MOSFET, high side switching (HSS)
max. current rating
10 A, adjustable in 1 A steps
typical voltage drop U
ON
at
rated current (25 °C):
60 mV
tripping range at overload
1.01 … 1.30 x I
N
motor function:
Switching of 2 H-bridges possible
(X2: O1 & O2, X2: O6 & O7)
high current function
20 A outputs via parallel connection of two load outputs (X2: O1 … O10)
dimming function:
all outputs are high-frequency dimmable, frequency adjustable
4 outputs with 3 A max. continuous current
load output
Power MOSFET, high side switching (HSS)
max. current rating
3 A, adjustable in 1 A steps
typical voltage drop U
ON
at
rated current (25 °C):
75 mV
tripping range at overload
1.01 … 1.30 x I
N
dimmer function:
all outputs are high-frequency dimmable, frequency adjustable
Approvals
approval authority: KBA
Standard: ECE regulation No 10 (E1)
Rated voltage: DC 12/24 V
Part number
PP-M-CM500-000-0-Z-00
Table 4: Selection of technical data
*) For further information please see the relevant data sheet.
