Pedestrian opening distance and independent pedestrian auto-close time:-
(Default = ± 1m opening and 5sec. auto-close time)
Action Response
Gate midway and engaged
1. Program jumper on 2 beeps
2. Dip-switch 2 on
3. Press and release Set button Gate closes
4. At closed position Gate opens
Gate stops
Gate closes
8. At closed position Continuous beep
9. Dip-switch 2 off Continuous beep stops
To change the pedestrian parameters again without leav ing programming, repeat from point 2.
5. Press and release Set button at
required open distance
6. Press and hold Set button,
count
beeps for auto-close time.
1 beep = 1sec.
2 beeps = 2sec.
....cont
255 beeps = 4.25 min. (Max)
7. Release Set button at required
auto-close time
Remove program jumper or continue to another programming option
