The Alarm output will trigger if the BM (Beam) input is activated continuously for ≥ 20sec while the gate is in
the closed position. This output should be connected to an “ET Relay on board” which in turn can be
connected to a zone on the alarm system or simply a light that the user can easily see when approaching
the gate. In this way the user can identify if someone has tampered with the beams trying to prevent the
gate from closing again once they have entered the property.
The Beam alarm output will de-activate as soon as the interference/tamper is removed.
Additional functions
Action Response
Until 5sec beep begins.
To unlock repeat
Holiday lock-out
Av ailable in all but Complex Auto-close mode.
1. Close gate
2. Press and hold the PED (pedestrian)
button on a master remote
3. Release PED (pedestrian) button on
master remote
Beeping will continue until confirmation or
5sec expires.
4. Press and release BT (full opening)
button on the master remote before 5sec
beep stop.
1 x multiple rapid beeps will confirm
holiday lock-out is activ e.
After multiple confirmation beeps gate
will immediately start opening when
unlocked.
Holiday lock-out is av ailable only when using a master remote. (No hardwired dev ices will activ ate)
A master remote is a remote that has BT (full opening) control as well as PED (Pedestrian) opening control.
If no BT (full opening) confirmation trigger is receiv ed by the time the intermittent beeps stop (5sec.), the gate
will not change status.
