Operating mode selection
(Program jumper off)
Dip-switch selection Mode
Dip-switch 1 ON (only) Simple Auto-close
As per Standard mode abov e howev er the following differs: -
The unit times out the pre-programmed auto-close time when stopped in any open position. Once the
auto-close time has expired it begins closing the gate.
While closing the gate any BT (full opening) or BM (beam) input will stop and rev erse the motor direction
back towards the full open position.
In any open position while auto-close is timing out a BM (beam) input will reset the auto-close timer.
Auto-close ov erride/Party mode is av ailable in this mode. (See additional features below)
Holiday lock out is av ailable in this mode. (See additional features below)
Master remote programming is av ailable in this mode. (See page 23)
Dip-switch selection Mode
All off Standard (Four step logic)
When the motor is activ ated using any BT (full opening) input the gate will open or close and can be
stopped in mid cycle using any BT (full opening) input again.
The gate can then be rev ersed by activ ating the BT (full opening) input again.
In this mode the gate will remain open where it has been stopped either by button or open limit until the BT
(full opening) input is activ ated again. (No auto close)
Party mode is av ailable in this mode. (See additional features below)
Holiday lock out is av ailable in this mode. (See additional features below)
Master remote programming is av ailable in this mode. (See page 23)
