Learning a TX button for BT (Full opening) operation using the RX (receiver) Master remote: -
(25 user memory)
Action Response
Continues to beep.
To continue adding remotes repeat from point 2.
The RX (receiv er) Master remote can only be learnt into memory using the RX (receiv er) pins!
The RX (receiv er) Master remote is the first remote learnt into the BT (full opening) memory and it
must be able to operate the PED(pedestrian) function of the built-in RX (receiv er) as well.
Feature not av ailable in Condo/loop mode
Feature limited to learning in BT (full opening) operation transmitters only.
1. Open gate fully using the
RX (receiv er) master remote
Gate runs to full open position and
stops
2. Press and hold RX
(receiv er) Master remote
pedestrian button.
Start of 5sec. Beep. Waiting for new
remote trigger.
3. Release RX(receiv er)
Master remote pedestrian
button
4. Press and hold required
button on new TX
(transmitter)before learn
mode timer expires and
beep stops.
Long beep changes to.....
2 beeps = Successful there is still memory
av ailable
Multiple rapid beeps = memory full
No beep = Button already in RX
(receiv er) memory or non ET Blue TX
(transmitter) used.
If no new TX (transmitter) button is pressed within 5 seconds of the continuous beep beginning,
then the RX (receiv er) will exit learn mode. All functions return to normal.
