Table of contents
Page Category
Introduction
3 Safety obligations and general warnings
4 Identification of components
5 Technical specifications
6 Before installing preparation
7 Cable requirements
Hardware installation
8
9 Installing the baseplate and positioning motor
10 Inserting or remov ing battery and mounting of motor to baseplate
11 Installing the rack
13 Installing the limit actuator
14 Control card wiring layout
Motor control programming
15 Run time set-up
16 Auto-close time programming
17 Pedestrian opening and pedestrian auto-close time programming
18 Changing the crawl distance
19 Changing the switch type input for the beams
20 Adjusting the safety sensing lev el
Receiver programming
21 Master erase
22 Registering a transmitter using the receiv er pins
23 Registering a transmitter using the master remote transmitter
Operating mode selection
24 Standard mode
24 Simple auto-close mode
24 Complex auto-close/Condominium mode
25 P.I.R.A.C. mode
Additional features
26 Holiday lock-out
26 Beam Alarm Output (B.A.O)
27 Auto-close ov erride/party mode
27 Pedestrian operation
27 Courtesy light functionality
Trouble shooting
28 Buzzer indication trouble shooting guide
28 Status LED indication guide
29
Warranty
Accessing manual override and remov ing cov er
