Installation and Wire Layout
2
Frame50：EC50030G0037P43B、EC50037G0045P43B
Frame40：EC518D5G0022P43B、EC50022G0030P43B
unit:mm
Frame30：EC50011G0015P43C、EC50015G18D5P43C
EC5000
Installation and Wire Layout
Frame11：EC502D2G03D0HP43C、EC503D0G04D0P43C、EC504D0G05D5P43C
Frame20：EC505D5G07D5P43C、EC507D5G0011P43C
unit:mm
