EACON EC5000 Series - Modbus Communication Address and Baud Rate; Modbus Communication Parity and Run Time

EC5000
- 90 - - 91 -
Description of Functional Parameter
5
■Modbus mode:
Please refer to Chapter 6 of the MODBUS communication protocol in EACN
the data structure the contents of the section.
■band：
0： 1200BPS
2： 4800BPS
4: 19200BPS
1： 2400BPS
3： 9600BPS
5: 38400BPS
0:7N2 For ASCII 1:7E1 For ASCII
2:7O1 For ASCII 3:8N2 For RTU
4:8E1 For RTU 5:8O1 For RTU
EC5000
Description of Functional Parameter
。
F04 transmitting run time setting limits：0～1 factory default：1
Set run-time test with MODBUS communication：
0：without run-time test
1：with run-time test
F05 CE stop setting limits：0～3 factory default：1
Stop method of communication error(EC)：
0：retard to stop(with retard time1)
1：slide to stop
2：retard to stop(with retard time2)
3：continue running(alarm)
F06 O H stop setting limits：0～3 factory default：3
Stop way when radiator overheat：
0 ：retard/stop 1(fault)
1 ：free stop
2 ：retard/stop2(fault)
3 ：continue running(alarum)
Braking resistance overheat protection function：
0： without braking resistance overheat protection
1： with braking resistance overheat protection
F07 DBR over heat setting limits：0～1 factory default：0
0 ：LOCAL/REMOTE key function: invalid
1 ：LOCAL/REMOTE key function: valid
F08 L / R function setting limits：0～1 factory default：0
0：When LOCAL/REMOTE shifting, re-run is valid when stop order is inputed
1：When LOCAL/REMOTE shifting, re-run is valid at once
F09 L / R sellection setting limits：0～1 factory default：0
F10 enter key setting limits：0～1 factory default：1
0 ：STOP key is always valid in any operating mode
1 ：STOP key is valid when operator is running within operator running order
0 ：“ENTER” key not used when set frequency order with operator
F11 Oper Enter Key setting limits：0～1 factory default：1
1 ：“ ENTER” key used when set frequency order with operator
F12 Variable Selection setting limits：0～2 factory default：1
Only LCD manipulator has this functional code
0: m/s
1: Mpa/mm²
2: Kg/ mm²
Pr-F12 fre set select setting limits：0～1 factory default：1
Only LCD manipulator has this functional code
0:Fre. set by key button number
1:Fre. set by key potentiometer adjustment
F13 LCD brightness setting limits：0～10 factory default：0
Only LCD manipulator has this functional code
Usd to adjust the brightness of LCD display
Pr-F13 data rewrite setting limits：0～2 factory default：0
Only LCD manipulator has this functional code
0: Data copy
1: Data check
2: Data write
F14 monitoring select setting limits：0～6 factory default：0
