Fu nct ion C ode T abl e
EC 600 0
Fu nct ion C ode T abl e
EC 600 0
P2-09
P2-10
Vector control
over-excitation
gain
Torque upper
limit source
in speed
control mode
0～200
0: P2-11 function code setting
1: AI1 2: AI2 3: AI3
4: Pulse setting
5: Communication setting
6：MIN(AI1,AI2) 7：MAX(AI1,AI2)
64
0
0209H
020AH
150.0%
-
-
2000
1300
2000
1300
P2-11
P2-12
P2-13
P2-14
P2-15
P2-16
P2-17
020BH
020CH
020DH
020EH
020FH
0210H
0211H
0.0～200.0%
-
-
0～60000
Digital setting
of torque
upper limit
Reserved
Current loop
of M-axis Kp
Current loop
of M-axis Ki
Current loop
of T-axis Kp
Current loop
of T-axis Ki
Reserved
0
P2-18 0212H
Speed loop
integral
property
0: Invalid
1: Valid
P2-19
Over
excitation
mode selection
0213H
0: Disable
1: Reduce process enable
2: Constant speed and deceleration
1
P2-20
P2-21
0～1
100～110%
0
105%
0214H
0215H
Over
modulation
enable
selection
Maximum output
voltage
cofficient
P2-22
0～1
50～200%
0
100%
P2-23
0216H
0217H
Field
weakening
automatic
adjustment
gain
Negative
torque
limit enable
P3 V / F Co ntr ol Pa ra met ers
Function
Code
P3-00
P3-01
P3-02
P3-03
P3-04
P3-05
P3-06
P3-07
P3-08
P3-09
Parameter Name
V/F curve
selection
Multi-point
V/F frequency1
(F1)
Multi-point
V/F voltage1 (V1)
Multi-point
V/F frequency2
(F2)
Multi-point
V/F voltage2 (V2)
Multi-point
V/F frequency3
(F3)
Multi-point
V/F voltage3 (V3)
V/F Torque boost
Cut-off
frequency of
torque boost
V/F slip
compensation
Address
0300H
0302H
0301H
0304H
0303H
0306H
0305H
0307H
0308H
0309H
Setting Range
0: Linear V/F
1：Set P0-03 ~ P3-06 parameter to obtain any
V/F relationship curve
2: Square V/F
3: 1.2-power V/F 4: 1.4-power V/F
6: 1.6-power V/F 8: 1.8-power V/F
9: Reserved 10: V/F complete separation
11: V/F half separation
0.00～P3-03
0.0～P3-04
P3-01～P3-05
P3-02～P3-06
P3-03～maximum frequency
P3-04～100%
0.0～30.0%
0.00～maximum frequency
0～200.0%
Default
0
1.00Hz
3.0%
25.00Hz
50.0%
50.00Hz
100%
1.0%
50.00Hz
0.0%
P3-10
Slip compensation
time constant
030AH
0.1～10.0s 0.5s
P3-11
P3-12
0～2.00
0.64
030BH
030CH
030DH
030EH
Over excitation
gain
Online torque
compensation gain
80～150
100
P3-14
P3-15
P3-13
V/F oscillation
suppression gain
0～1000
Model
dependent
030DH
Oscillation
suppression
mode selection
0～4
3
Voltage source
for V/F
separation
selection
0: Digital setting (P3-15)
1: AI1 2: AI2 3: AI3
4: Pulse setting (S5) 5: Multi-reference
6: Simple PLC 7: PID
8: Communication setting
0
