Item
Specifica t i o n s
LED display
LCD display
It displays the parameters.
Optional, Chinese/English prompt operation content
Parameters copy
Quick copying of parameters can be realized through LCD
operation panel option.
Key locking and
function selection
Protection mode
It can lock the keys partially or completely and define
the function range of some keys so as to prevent mis-
function.
Motor short-circuit detection at power-on, input/output
phase loss protection, overcurrent protection, over-
voltage protection, undervoltage protection, overheat
protection and overload protection
Installation
location
Indoor, free from direct sunlight, dust, corrosive gas,
combustible gas, oil smoke, vapour, drip or salt.
Altitude
Ambient temperature
Lower than 100 0 m
Display
and
operation
on the
operation
panel
Optional par t s
LCD operation panel, braking unit, I/O extension card 1,
I/O extension card 2, user programmable card, RS485
communication card, PROFIBUS-DP communication card,
CANlink communication card, CANopen communication card,
differential input PG card, UVW differential input PG
card, resolver PG card and OC input PG card
Environ-
ment
Humidity
Vibration
Less than 95%RH, without condensing
Less than 5.9m/s (0.6g)
Storage
temperatur e
IP level
IP20
Pollution degree
PD2
-20 ～+60
°
C
°
C
-10°C to +40°C (de-rated if the ambient temperature is
between 40°C and 50°C)
Te chn ica l Spe cif ica tio ns
EC 600 0
Me cha nic al di men sio n of AC d riv e
EC 600 0
4. Mec han ica l dim ens ion o f AC dr ive
A Struct u r e
B Struct u r e
- 6 -
- 7 -
Protection
mode
Op ti on al
pa rt s
D1
D
W
W1
H
H1
Installation Hole
D1
DW
W1
H
H1
Installation Hole
W1
