EACON EC6000 Series - 9 Function Code Table: Analog Terminals; P5 Analog Terminal Parameters

- 26 -
- 27 -
Fu nct ion C ode T abl e
EC 600 0
Fu nct ion C ode T abl e
EC 600 0
30：Module temperature Reached
31：Fan running
32: Data output 1 from transfer(Y function)
33: Data output 2 from transfer(Y function)
34: Data output 3 from transfer(Y function)
35: Data output 4 from transfer(Y function)
36: Pump 1 start-up
37: Pump 2 start-up
38: Pump 3 start-up
39: Pump 4 start-up
P4-26
Y7 terminal
function-
Extension
0
041AH
P4-27
Y8 terminal
function-
Extension
0
041BH
P5 A n al og te rmi na l par ame te r s
P5-00
P5-01
Function
Code
AI123
input signal
selection
AI1 input voltage
minimum value
Parameter Name
BIT0: AI2 signal selection
0：0～10V 1：0～20.00mA
BIT1: AI3 signal selection
0：0～10V 1：0～20.00mA
BIT2: AI3 signal selection
0: 0～10V 1: 0～20.00mA
BIT3: Reserved
0.00～10.00V
Setting Range
0010
0.00V
Default
0500H
0501H
Address
P5-02
AI1 input voltage
lower limit
corresponding
setting
0.00～100.00%
0.00%
0502H
P5-03
AI1 input voltage
maximum value
0.00～10.00V 10.00V 0503H
P5-04
AI1 input voltage
upper limit
corresponding
setting
0.00～100.00% 100.00% 0504H
P5-05
AI1 filter time
0.00～10.00s 0.10s 0505H
P5-06
AI2 input voltage
minimum value
0.00～10.00V
0.00V
0506H
P5-07
AI2 input voltage
lower limit
corresponding
setting
0.00～100.00%
0.00%
0507H
P5-08
AI2 input voltage
maximum value
0.00～10.00V 10.00V 0508H
P5-09
AI2 input voltage
upper limit
corresponding
setting
0.00～100.00% 100.00% 0509H
P5-10
AI2 filter time
0.00～10.00s 0.10s
050AH
P5-11
AI3 input voltage
minimum value
0.00～10.00V
0.00V
050BH
P5-12
AI3 input voltage
lower limit
corresponding
setting
0.00～100.00%
0.00%
050CH
P5-13
P5-14
AI3 input voltage
maximum value
AI3 input voltage
upper limit
corresponding
setting
050DH
050EH
0.00～10.00V
0.00～100.00%
10.00V
100.00%
P5-15
P5-16
P5-17
P5-19
AI3 filter time
HS minimum input
frequency
Corresponding
setting of HS
minimum input
frequency
Corresponding
setting of HS
maximum input
frequency
050FH
0510H
0511H
0513H
0.00～10.00s
0.00～50.00KHz
0.00～100.00%
0.00 100.00%～
0.10s
0.00KHz
0.00%
100.00%
P5-18 0512H
0.00～50.00KHz 50.00KHz
HS maximum input
frequency
P5-20
P5-21
～
P5-28
HS filter time
Reserved
0.00～10.00s
-
0.10s
-
0514H
0515H
～
051CH
P5-29
A01 output
selection
051DH
0
0: Set frequency 1: Output frequency
2: Output current 3: Output voltage
4: Mechanical speed 5: Set torque
6: Output torque 7: PID setting
8: PID feedback 9: Output power
10: Bus voltage 11: Input voltage
12: AI1 input value 13: AI2 input value
14: AI3 input value
15: PUL input value
16: Module temperature
17: Internal temperature
18: Excitation quantity
19: RS485 communication settings
P5-30
A02 output
selection
051EH
1
P5-31
P5-32
HY output
selection
Analog output
signal selection
051FH
0520H
BIT0: AO1 signal selection
0：0～10V
1：4.00～20.00mA
2：0.00～20.00mA
BIT1: AO2 signal selection
0: 0-10V
1: 4.00-20.00mA
2: 0.00-20.00mA
BIT2: HY function enable
0: Ordinary switching value Y4 function
1: HY high speed pulse output function
BIT3: Reserved
2
000
