Fu nct ion C ode T abl e
EC 600 0
Fu nct ion C ode T abl e
EC 600 0
040AH
P4-10
0000
BIT0: S5 terminal
0: Effective closing 1: Effective opening
BIT1: S6 terminal
0: Effective closing 1: Effective opening
BIT2: S7 terminal
0: Effective closing 1: Effective opening
BIT3: S8 terminal
0: Effective closing 1: Effective opening
Characteristic
selection of
terminal S5-S8
Characteristic
selection of
terminal S1-S4
0408HP4-08 000 0
BIT0: S1 terminal
0: Effective closing 1: Effective opening
BIT1: S2 terminal
0: Effective closing 1: Effective opening
BIT2: S3 terminal
0: Effective closing 1: Effective opening
BITE: S4 terminal
0: Effective closing 1: Effective opening
0409HP4-09
0.10s
0.000～60.00s
Filter time of
terminal S1-S4
040BH
P4-11
0.1s
0.000～60.00s
Filter time of
terminal S5-S8
0: Two-line mode 1
Terminal set as 1 is forward running,
terminal set as 2 is reverse running
1: Two-line mode 2
Terminal set as 1 is start running,
terminal set as 2 is switch forward and
reverse running
2: Three-line mode 1
Terminal set as 1 is forward running,
terminal set as 2 is reverse running,
terminal set as 3 is stop running
3: Three-line mode 2
Terminal set to 1 is start running,terminal
set as 2 is switch forwardand reverse,
terminal set as 3 is Stop running
P4-12
Terminal
command mode
040CH0
P4-13
Terminal
action mode
selection
040DH
111
BIT0: Terminal of coast to stop
recovery mode
0: Restore the original instruction after
invalidation
1: Do not restore the original instruction
after invalidation
BIT1: Terminal of emergency stop recovery
mode
0: Restore the original instruction after
invalidation
1: Do not restore the original instruction
after invalidation
BIT2: Select the terminal operation mode
after fault reset
0: The terminal operation command is valid
immediately
1: The terminal operation command is valid
only after it is canceled
P4-16
P4-17
P4-18
Terminal
protection
function
selection
UP/DW frequency
value
UP /DW frequency
adjustment
selection
BIT0：
0: Invalid terminal operation command when
power on
1：Valid terminal operation command when
power on
BIT1: When the run command setting channel
terminal switching,selection of run command
is valid
0: The running command is valid after
stopping during switching
1: The run command is valid immediately when
switching
0.0～1.000
0: Retentive at power failure
1: Non-retentive at power failure
2: Valid operation, stop and reset
00
0.01
0
0410H
0411H
0412H
P4-14
Reserved
- -
040EH
P4-15
Reserved
- -
040FH
0.1～100.0%/sP4-19
Speed of UP/DW
frequency
increase
and decrease
2.0 % /s
0413H
P4-20
Y1 terminal
function
1
0414H
P4-21
Y2 terminal
function
2
0415H
P4-22
Y3 terminal
function
3
0416H
0：No output
1：Forward running 2：Reverse running
3：Fault output1 (no output at auto-reset
period)
4：Fault output2 (output at auto-reset
period)
5：Ready for RUN
6：Frequency reached
7：Frequency-level detection FDT1 output
8：Frequency-level detection FDT2 output
9：Frequency upper limit reached
10：Frequency lower limit reached
11：Current 1 reached
12：Current 2 reached
13：Zero current output
14：Output current out of limit
15：Torque limited
16：OL1 motor overload pre-warning
17：OL2 AC drive overload pre-warning
18：Zero-speed running (no output at stop)
19：Acceleration running
20：Deceleration running
21：Dc breaking
22：PLC step completed
23：PLC cycle completed
24：Reserved
25：Accumulative running time reached
26：Timing reached
27：Maximum count value reached
28：Set count value reached
29：AI1 input out of limit
P4-23
Y4 terminal
function
6
0417H
P4-24
Y5 terminal
function-
Extension
0
0418H
P4-25
Y6 terminal
function-
Extension
0
0419H
