Fu nct ion C ode T abl e
EC 600 0
Fu nct ion C ode T abl e
EC 600 0
0D1FH
00
PD-31
Running
direction and
acceleration/
deceleration
time of PLC
reference 1
0D20H00PD-32
Running
direction and
acceleration/
deceleration
time of PLC
reference 2
0D21H
00PD-33
Running
direction and
acceleration/
deceleration
time of PLC
reference 3
BIT0: Operation direction of this section
0: Forward 1: Reverse
BIT1: Acceleration and deceleration time of this
section
0: Acceleration and deceleration time 1
1: Acceleration and deceleration time 2
2: Acceleration and deceleration time 3
3: Acceleration and deceleration time 4
BIT2: Reserved BIT3: Reserved
0D22H00PD-34
Running
direction and
acceleration/
deceleration
time of PLC
reference 4
0D23H00PD-35
Running
direction and
acceleration/
deceleration
time of PLC
reference 5
0D24H00PD-36
Running
direction and
acceleration/
deceleration
time of PLC
reference 6
0D25H00PD-37
Running
direction and
acceleration/
deceleration
time of PLC
reference 7
0D26H00PD-38
Running
direction and
acceleration/
deceleration
time of PLC
reference 8
0D27H
00
PD-39
Running
direction and
acceleration/
deceleration
time of PLC
reference 9
0D28H00PD-40
Running
direction and
acceleration/
deceleration
time of PLC
reference 10
0D29H00
PD-41
Running
direction and
acceleration/
deceleration
time of PLC
reference 11
0D2AH
00
PD-42
Running
direction and
acceleration/
deceleration
time of PLC
reference 12
BIT0: Operation direction of this section
0: Forward 1: Reverse
BIT1: Acceleration and deceleration time of this
section
0: Acceleration and deceleration time 1
1: Acceleration and deceleration time 2
2: Acceleration and deceleration time 3
3: Acceleration and deceleration time 4
BIT2: Reserved BIT3: Reserved
0D2BH00PD-43
Running
direction and
acceleration/
deceleration
time of PLC
reference 13
0D2CH00
PD-44
Running
direction and
acceleration/
deceleration
time of PLC
reference 14
0D2DH00PD-45
Running
direction and
acceleration/
deceleration
time of PLC
reference 15
PD-46
Swing frequency
control
BIT0: Swing frequency setting mode
0: Invalid swing frequency control
1: Effective swing frequency control
BIT1: Frequency swing input mode
0: Automatic input 1: Manual input
BIT2: Swing control
0: Variable swing 1: Fixed swing
BIT3: Reserved
0D2EH00
PD-47
Preset
frequency
of swing
frequency
0.00Hz
0D2FH
0.00～maximum frequency
