5.4 Operation instructions
To avoid personal injury and/or property damage, permit only trained personnel to operate the lift.
After reviewing these instructions, get familiar with lift controls by running the lift through a few cycles before loading vehicle on
lift. Always lift the vehicle using all four adapters. Never raise just one end, one corner or one side of vehicle.
The lift must be only used in a static position for lifting and lowering vehicles.
The normal users are not allowed to open the door of control cabinet.
Raise the lift
Make sure vehicle is neither front nor rear heavy and center of balance should be midway between adapters and centered over t he
lift.
1. Make sure that you have read and understood the operation manual before operation.
2. Load vehicle on lift carefully. Position the lift adapters to contact at the vehicle manufacturer’s recommended lift points.
3. Push the UP button to raise lift until adapters contact vehicle.
4. Check adapters for secure contact with vehicle. Raise lift to expected working height.
Lower the lift
When lowering the lift pay careful attention that all personnel and objects are kept clear.
1. Push the DOWNI button to lower the lifting platform. It will stop lowering at safety height.
2. Push DOWN II button to continue lowering the platforms which accompanies with safety alarming buzz.
3. After the lifting platform is fully lowered, remove rubber pads and other tools to provide an unobstructed exit for moving vehicle from the
lift area.
4. Drive the vehicle away.
