Installation, Operation and Parts Manual
EE-6503V2
26
Pos.
Code
Name
Specification
Qty
T
320101016
Transformer (380V)
JBK3-63VA 380V-24V
1
320101017
Transformer (400V)
JBK3-63VA 400V-24V
1
320101018
Transformer (415V)
JBK3-63VA 415V-24V
1
320101011
Transformer (220V)
JBK3-63VA 220V-24V
1
320101013
Transformer (230V)
JBK3-63VA 230V-24V
1
320101014
Transformer (240V)
JBK3-63VA 240V-24V
1
M
Motor
2.2kW or 3.0kW
1
QF
320802001
Circuit breaker (1Ph)
DZ47-63C32/2P
1
320801001
Circuit breaker (3Ph)
DZ47-63C16/3P
1
QF1
320803001
Circuit breaker
DZ47-63C1/1P
1
KM
320901001
AC contactor (3Ph)
CJX2-1210/AC24
1
320901011
AC contactor (1Ph)
CJX2-1810/AC24-220V-1P
1
SQ1,SQ2
320301011
Limit switch
TZ8108
2
QS
320304001
Power switch
LW26GS-20/04
1
SB
320402002
Emergency stop
XB2BS542C/NP2BS542
1
320503002
Ground terminals
4P
1
HL
321201001
Power indicator
AD17-22G-AC/DC24
1
FA
321202001
Alarm buzzer
AD17-22SM/AC/DC24
1
SB1,SB2
320401038
Button
NP2-EA13C
2
792224006
PCB board
6503V2M
1
321203145
PCB spacer rod
DCB-7
4
NOTE: For power supply of other voltages, the transformer is different.
Please check with our customers service people when order spare parts.
