Mode of Buttons
Left Up Right Down
Left Down Right Up
Select which rocker button is “Up
Button” and which rocker button
is “Down Button”.
Control Type
Shutter/Venetian Blind
Blind/Roller/Awning
Selects control type of blinds.
Shutter/Venetian Blind function
includes “Lamella Control” and
Blind/Roller/Awning function does
not include “Lamella Control”.
Function of LED
LED Permanently Off
LED always off
LED Permanently On
LED always on
Status Indication
Visualize blind’s state using status
LEDs of up and down buttons. *[5]
Operation Indication
Status LED of the pressed rocker
button will be on for the time
period selected at “Light Duration
of LED” parameter at “General”
tab.
Long Press Duration
300ms/ 400ms/ 500ms/ 600ms/
800ms / 1s / 1.2s / 1.5s/ 2s / 3s /
4s / 5s / 6s / 7s / 8s / 9s / 10s
Time interval to switch from short
press to long press
Table 10
*[5] LED Function – Status Indication
Status indication operates the same way for “Shutter/Venetian Blind” and “Blind/Roller/Awning”. LEDs status
respective to blind’s state is given below
Up Button - Status LED
Down Button - Status LED
Moving upward
Blink
Off
Moving downward
Off
Blink
At top position
On
Off
At bottom position
Off
On
Stop between top - bottom
Off
Off
Table 11
When “Function of Led” selected as “Status Indication”, “Top Position” and “Bottom Position” communication
objects given below must be linked to the appropriate group addresses for the status LEDs to function
correctly.
4.2.1.3.2 Communication#Objects#
No
Object Name
Function
Data Type
Flags
1
Rocker1-shutter
UP/DOWN
Up/Down
1 bit
DPT 1.008
CWT
This communication object will be used to start blind movement.
2
Rocker1 –
STOP/Lamella adj.
Stop/Lamella adj.
1 bit
DPT 1.002
CWT
When “Control Type” parameter is “Shutter/Venetian Blind” this communication object is used to stop
movement of blind and adjust lamella position, otherwise when “Control Type” parameter is
“Blind/Roller/Awning” only used for stopping blind movement.
3
Rocker1-Top
Position
True/False
1 bit
DPT 1.002
CWT
