Transmitted value [-32768…32767]
-32768… 0 …32767
Visible when “Data Type” selected
as “2 byte value [-32768…32767]”.
Transmitted value [0…65535]
0 …65535
Visible when “Data Type” selected
as “2 byte value [0…65535]”.
Float decimal
-128… 0 …127
Visible when “Data Type” selected
as “4 byte value [floating point]”.
Float rational
0 …99
Visible when “Data Type” selected
as “4 byte value [floating point]”.
Transmitted value
[0…4294967295]
0…4294967295
Visible when “Data Type” selected
as “4 byte value [0…4294967295]”.
Right Button of Rocker – Operate the same way as Left Button of Rocker
Table 13
4.2.1.4.2# Communication#Objects#
No
Object Name
Function
Data type
Flags
1
PushButton1 – value[0,1]
True/False
1 bit
DPT 1.002
CWT
Enabled when “Data Type” selected as “1 bit value”
PushButton1– value[0…255]
Send
1 byte
DPT 5.010
CWT
Enabled when “Data Type” selected as “1byte value [0…255]”
PushButton1– value[0…255]
Send
1 byte
DPT 5.001
CWT
Enabled when “Data Type” selected as “Percent value [%0…%100]
PushButton1- value[-32768…32767]
Send
2 byte
DPT 8.001
CWT
Enabled when “Data Type” selected as “2 byte value [-32768…32767]”
PushButton1- value[0…65535]
Send
2 byte
DPT 7.001
CWT
Enabled when “Data Type” selected as “2 byte value [0…65535]”
PushButton1- value[temperature]
Send
4 byte
DPT 14.068
CWT
Enabled when “Data Type” selected as “4 byte value [floating point]
PushButton1-value[0…4294967295]
Send
4 byte
DPT 12.001
CWT
Enabled when “Data Type” selected as “4 byte value [0…4294967295]”
2
PushButton1-long – value[0,1]
True/False
1 bit
DPT 1.002
CWT
Enabled when “Long Press Data Type” selected as “1 bit value”
PushButton1-long – value[0…255]
Send
1 byte
DPT 5.010
CWT
Enabled when “Long Press Data Type” selected as “1byte value [0…255]”
PushButton1– value[0…255]
Send
1 byte
DPT 5.001
CWT
Enabled when “Long Press Data Type” selected as “Percent value [%0…%100]
PushButton1 - long- value[-
32768…32767]
Send
2 byte
DPT 8.001
CWT
Enabled when “Long Press Data Type” selected as “2 byte value [-32768…32767]”
PushButton1- long -
value[0…65535]
Send
2 byte
DPT 7.001
CWT
Enabled when “Long Press Data Type” selected as “2 byte value [0…65535]”
